Gold testers


Universal Testing Machine gold purity testing machine NAP8200MB

Name:Universal Testing Machine gold purity testing machine NAP8200MB

Details

This gold tester is integrated an industrial computer with industrial motherboard & multi-point hand touch. Providing best operation experience.
It is designed exactly to security standards with active radiation protection, high voltage protection and X-ray tube overheating protection. Warm-up and anti interference procedure is controlled by the program, to reduce the interference by the reflected X-ray and the spectrums, to add the accuracy and stability.
Optional colors for different elements will help to distinguish the interested elements clearly and conveniently. When the testing is over, the testing report will be shown timely.



working priciple: Energy dipersive X-ray fluorescence

Detector:

gas proportional detector
Testerbale Elements: gold,silver,copper,Zinc,Nickel,Platinum and etc. Precision: 0.1%
Size: 650*550*550 Gross weight 45 KG



  • Competitive Advantage :
  1. Non-destructive and Precision
  2. Fast(testing time is about 30s-200s)
  3. Small samples could be tested
  4. Could read not only the gold percentage but also the other metels in the sample
  5. Could print out the testing report,also the testing data

  6. hand-touching screen

  7. Could save all data into the main server

  8. FCC,CE ,RoHS approved.

  • Product uniqueness
  1. XRF Version 3.0 menu mode is adopted with parameter setting, data inspection and calculation.Both of English and Chinese version are available
  2. Testing time is fixed by the program to improve the capability and efficiency, without assistance
  3. The self-protection technology is able to enhance the consumption life of the X-ray tube. Warm-up and anti interference procedure is controlled by the program, to reduce the interference by the reflected X-ray and the spectrums, to add the accuracy and stability.
  4. Optional colors for different elements will help to distinguish the interested elements clearly and conveniently. When the testing is over, the testing report will be shown timely.
  •   Applications

  Fast, precise and non-destructive metal testing for jewellery retailers, jewellery manufacturers, precious metal refineries, pawn shops, government quality inspection departments, banks, laboratories and tertiary institutions.



  • Hot Name:

gold scanner detector / best metal detector / gold tester / gold karat tester / spectrometer /  metal spectrometer / xrf metal analyzer / precious metal analyzer / metal analyzer spectrometer / gold purity testing machine, gold purity testing / best gold detector/ XRF Machine /  Spetrometer



                          Best guarantee and warranty



Quick Detail:



NAP8200MB provides the lowest cost option for gold purity analysis needs. A proportional counter system, this the lowest priced X-ray fluorescence unit in the gold tester filed.

Competitive Advantage:



1, WIth high-tech state of art built-in  computer


2.Fast and accurate analysis



3, With touch screen operation


4.Easily use,software with minimal training



5, X-ray Tube overheating protection


6.Provide with on line training



7,  Cool advanced plastic material body


Applications:



Fast, precise and non-destructive metal testing for jewellery retailers, jewellery manufacturers, precious metal refineries, pawn shops, government quality inspection departments, banks, laboratories and tertiary institutions.



Specifications:





Working Principle:

Energy Dispersive X-ray Fluorescence

Size(mm):

650*550*550

Detection limit:

100ppm Best substance effect

Precision:

±10ppm~0.2%

Expanded Uncertainty:

≤0.36%

Operating Environment:

Temperature 0-28℃

Humidity ≤70%

High Voltage:

0~50KV/0~1MA

Detector:

Gas Proportional Detector

Testable Elements:

Au, Ag, Cu,  Pt, Pd, Ir,Cd,ect.

Hare Ware:

Integrated PC with touch screen, Wireless LAN, USB interfaces, Video camera

Main Structure:

High-strength metal frame and industry plastic shell

N/G Weight(KG):

35 / 45



8200MB gold purity testing
